ISBN 9783843919692

Euro 72,00 inkl. 7% MwSt


978-3-8439-1969-2, Reihe Ingenieurwissenschaften

Christoph Hahn
A Simulation Approach of Permeability Prediction for RTM Process Simulation (Band 10)

169 Seiten, Dissertation Technische Universität München (2014), Softcover, A5

Zusammenfassung / Abstract

Following the trend of growing fiber composite materials usage, process automation and increasing component complexity, there arises a need for process simulation. The work presented here addresses a fast and robust characterization method of permeability for RTM process modeling. A simulation approach is presented based on fabric images, image processing and textile modeling.

For validation of the simulation approach a two-step validation approach was followed. At first, a test setup for permeability testing was developed and put into service. A test campaign focusing on non-crimp fabrics (NCF) gave the permeability results for comparison of material data. In a second step the simulation approach was employed to predict the fill time and flow front pattern of a complex component. The permeability results from experiments and the simulation approach showed excellent correlation for two biaxial non-crimp fabrics. For the fill time prediction of the RTM component, the simulation approach gave the best results and the flow front pattern could be predicted reasonably well.
